ISSN: 1885-5857 Impact factor 2025 4.2
Vol. 78. Num. 8.
Pages 747 (August 2025)

Image in cardiology
Frozen elephant trunk rupturing into the false lumen

Ruptura de la trompa de elefante congelada hacia el falso lumen

Haochen WangHui YuZhenghua Xiao
https://doi.org/10.1016/j.rec.2024.12.010

Options

Imagen extra
Rev Esp Cardiol. 2025;78:747

A 45-year-old man with severe, tearing chest pain was admitted to the emergency department. Computed tomography angiography (CTA) revealed a Stanford type A aortic dissection, with the primary entry tear located at the origin of the left subclavian artery. The patient underwent total arch replacement combined with a frozen elephant trunk (FET) procedure.

On postoperative day 1, the patient was successfully extubated in the intensive care unit. However, blood tests revealed a lactate value of 7.4, accompanied by hepatic and renal insufficiency, indicating severe renal and liver malperfusion. Urgent CTA demonstrated the accidental rupture of the FET graft into the false lumen (FL), resulting in compression of the true lumen (TL) (figure 1A).

Figure 1
(0.08MB).

Emergent intima fenestration and thoracic endovascular aortic repair (TEVAR) were performed. Intraoperatively, it was found that the FET graft had penetrated the FL of the descending aorta, causing severe occlusion of the TL and involving the celiac trunk artery, superior mesenteric artery, and left renal artery (video 1 of the supplementary data). An atrial septal puncture needle was used to fenestrate the membrane into the TL (figure 1B; video 2 of the supplementary data), followed by the deployment of a thoracic endovascular stent graft (Endovastec, China) to cover the rupture caused by the FET graft. Angiography confirmed the restoration of intra-abdominal aortic blood flow (video 3 of the supplementary data). Postoperative CTA, performed 2 days after the procedure, indicated the successful reversal of organ malperfusion through the fenestrated TEVAR (figure 1C).

FUNDING

This study was supported by grants from the Sichuan Science and Technology program: 2024YFFK0358. The funders had no role in the study design, data collection and analysis, writing of the manuscript, or decision to submit the article for publication

ETHICAL CONSIDERATIONS

Informed consent was obtained from this patient for this publication. This article does not address sex and gender in accordance with the SAGER guidelines. No studies have yet shown that postoperative frozen elephant trunk rupturing into the false lumen is affected by sex and gender.

STATEMENT ON THE USE OF ARTIFICIAL INTELLIGENCE

No artificial intelligence was used in the preparation of this article.

AUTHORS’ CONTRIBUTIONS

H. Wang contributed to writing the manuscript, collecting data, and processing the images. H. Yu revised the manuscript and assisted in processing the images. Z. Xiao performed the surgery, provided guidance during the writing process, reviewed the manuscript, and gave final approval for the version to be published.

CONFLICTS OF INTEREST

Nothing to disclose.

H. Wang and H. Yu contributed equally to the study.
